In many respects, car maintenance involves a balancing act. Wait too long between tune-ups and your car might suffer for it. But being over-zealous can lead to unnecessary costs, both money and time.
Your vehicle is a complex piece of engineering. Installing or replacing components, in particular, must be done carefully. If something doesn’t fit the way it should or isn’t installed correctly, it can affect how your automobile performs.
This very much applies to spark plugs, and in this article, we answer the question: how tight should spark plugs be?
Below, we discuss the symptoms associated with over and under-tightened spark plugs.
You’ll learn how to find out if yours are tightened correctly, and the proper installation procedure to get it right.
- How Tight do Spark Plugs Need to Be?
- What Will Happen if Spark Plugs are Too Loose?
- What Will Happen if Spark Plugs are Too Tight?
- How to Know Spark Plugs Aren’t Too Loose or Too Tight?
- How to Tighten Spark Plugs
- Equipment Needed:
- Step 1: Allow Engine Time to Cool Down
- Step 2: Disconnect Battery
- Step 3: Wipe Down Loose Debris
- Step 4: Removal: Use Penetrating Oil If Stuck
- Step 5: Clean Cylinder Heads
- Step 6: Ensure Replacements Aren’t Damaged
- Step 7: Gap New Plugs
- Step 8: Use Your Fingers to Screw it In
- Step 9: Tighten: Be Careful
- Step 10: Reattach Wire and Boot
- Going to a Professional to Tighten Spark Plugs: What to Expect
- How Tight Should Spark Plugs Be? Wrapping it Up
How Tight do Spark Plugs Need to Be?
Without spark plugs, your car could not run. They provide the spark to ignite the fuel-air mixture, the driving force of power in an internal combustion engine.
Unfortunately, there’s no such thing as universal plugs. The diameter and build can vary based on their intended usage. For instance, units for an eight-cylinder engine won’t be the same as ones for a four-cylinder.
If you’re unsure what size your spark plugs should be, refer to the user manual. Once you know the correct size needed, follow our correct installation practices below. This way, no matter what car you have, you will end up with an optimal fit.
What Will Happen if Spark Plugs are Too Loose?
Thanks to your engine mount, you shouldn’t hear or feel your motor much from the cabin. Older vehicles may be equipped with rubber mounts, whereas newer ones have hydro-elastic varieties.
Despite this, it’s impossible to repress vibrations internally. Improperly fitted plugs can grow looser the longer you drive around with them.
Naturally, this will influence how affected cylinders perform. Imagine plugging an electrical device in only halfway—it won’t work very well.
If your plugs are too loose, your engine is highly likely to experience one of the following:
- Problems with engine performance.
- Dead cylinder.
Poor Engine Performance
One or more plugs that aren’t fully screwed into the cylinder heads can lead to:
- Trouble getting the engine to start.
- Slow, difficult acceleration.
A loose unit can overheat significantly, which can induce abnormal combustion. One common side effect of this is pre-ignition.
The fuel-air mixture alights due to an overheated surface—such as that of the plug. Normally, this should only occur when it sparks.
Pre-ignition can encourage detonation. This is spontaneous combustion inside the engine that can manifest as pinging or knocking. Engine damage or total failure are typical results of this detonation.
If the poorly-installed unit is too loose, it could pop out. A dead cylinder, while the vehicle is in motion, can be a shock to you and your motor.
What Will Happen if Spark Plugs are Too Tight?
Remember that balance we talked about earlier? Plugs that are too snug can have unpleasant repercussions too, including:
- Stuck units that won’t come out.
- Damaged cylinder head.
- Pieces of the broken unit falling into the combustion chamber.
Hard or Impossible to Remove
At the least, removing an over-tightened spark plug will be difficult. Worst case scenario, it won’t come out at all.
It may even appear as though the spark plug has melded with the head of the cylinder. Deposits, debris, and potential corrosion build-up can behave like glue.
Damaged Cylinder Head
The bolt hole inside the cylinder head needs to stay intact. If it’s stripped or otherwise deformed, a replacement can’t be installed.
Removal of a jammed spark plug can cause damage to the bolt hole. If the problem is severe, repair costs can be expensive.
Foreign Objects in Combustion Chamber
Broken pieces of the spark plug insulator or electrode can find their way into the combustion chamber. They can knock around, harming the parts and surfaces they hit.
How to Know Spark Plugs Aren’t Too Loose or Too Tight?
The surest way is to inspect and handle them directly. If they’re too loose, you may be able to turn it with your fingers. Too tight, and it won’t budge at all, even with a wrench.
There are several indicators that your installation may not have gone as smoothly as you thought. If any of these apply to you, pop the hood for a check.
Did you adhere to the manufacturer guidelines for fitting while installing?
Certain brands have separate specifications for new versus refitted units. For example, a new unit may require a third of a rotation with a spark plug wrench. One that you’ve cleaned and want to refit may require one-and-a-third rotations.
If you were using a torque wrench, were you aware of the suggested torque? Or did you play it by ear?
Hearing, feeling, or seeing breaks should never be dismissed. They’re signs that you may have gone overboard; fracturing the unit.
Erratic motor performance after a replacement could warn of poor installation. Take note of the symptoms we talked about earlier.
How to Tighten Spark Plugs
Don’t be intimidated if you got it wrong the first time. Follow our guidelines below for a successful replacement.
- New units (if old ones are faulty, broken or aged).
- Appropriately-sized spark plug wrench (preferable) or torque wrench.
- Clean rags.
- Penetrating oil (for trapped devices).
- Thread chaser or cylinder-head cleaning kit.
- Feeler gauge.
Our guidelines will help you avoid both extremes of loose and tight, for an optimal installation:
- Allow engine time to cool down completely.
- Disconnect battery.
- Wipe down loose debris.
- Removal: use penetrating oil if the unit is stuck.
- Clean cylinder heads.
- Ensure replacements aren’t damaged.
- Gap new plugs.
- Use your finger to screw it in.
- Use a wrench to tighten, being careful.
- Reattach wire and boot.
Step 1: Allow Engine Time to Cool Down
Give your motor time to cool off before you open the hood. Put your gloves on so that you don’t forget.
Step 2: Disconnect Battery
No one wants to get shocked while working. To keep yourself safe, disconnect the negative terminal, and set the connector aside.
Step 3: Wipe Down Loose Debris
Use your rags to wipe on and around the plugs. You don’t want any deposits or debris falling into the cylinder head during removal.
Step 4: Removal: Use Penetrating Oil If Stuck
Detach the spark plug boot and wire attached to the unit. If your wires aren’t labeled, either label them or work on them one at a time to avoid confusion.
Use your wrench of choice to unscrew it. If it isn’t coming out, apply penetrating oil and wait a while. This will dissolve the crud that’s holding it to the bolt hole.
Try again. If it’s still not coming loose, repeat an application of oil. Shift the unit backward with your fingers, re-tightening it, to distribute the oil.
You may have to do this back-and-forth several times. The goal is to loosen it without forcing it or breaking it.
Step 5: Clean Cylinder Heads
Using the thread chaser tool or cleaning kit will get rid of troublesome debris still caught in the bolt hole.
Step 6: Ensure Replacements Aren’t Damaged
It’s admittedly rare, but defects can happen. If you notice cracks or chips, dispose of the new plug.
Step 7: Gap New Plugs
Even if the manufacturer states they’re pre-gapped, double-check using your feeler gauge. Adjust as needed.
Step 8: Use Your Fingers to Screw it In
Position the unit and screw it in. If you come up against resistance, it may be at an angle. If so, reposition and try again.
Step 9: Tighten: Be Careful
Once it’s in, tighten the spark plug using the appropriate wrench to secure it. Stick to the manufacturer guidelines for recommended torque here; don’t go overboard.
Step 10: Reattach Wire and Boot
Once the installation is complete, reattach the spark plug wire and boot. Repeat the procedure with all the units that need to be replaced.
Going to a Professional to Tighten Spark Plugs: What to Expect
You’re not obliged to do this by yourself. You can go to your local mechanic and have them do the replacement for you.
This will cost you more, though. Expect to pay between $40–$150 for professional installation, excluding new units.
How Tight Should Spark Plugs Be? Wrapping it Up
The ideal tightness of spark plugs will depend on their specific type and the make and model of your vehicle.
Most importantly, be precise with the installation. Don’t rush, and be sure to use common sense. You don’t need herculean strength to tighten them; a light touch is enough.
